Dragon 龍


Specification 規格

DESIGN: 3 – way bass-reflex floor standing loudspeaker

FREQUENCY RESPONSE: 22-40K Hz ±2dB

SENSITIVITY (2.83V/1M): 90 dB

IMPEDANCE: 4 ohms

POWER REQUIREMENT: 50-150W recommended

TWEETER: Jantzen 1” Diamond

REAR FIRING TWEETER : Accuton 1” ceramic

MIDWOOFER 1&2 : Accuton 5”cell ceramic

WOOFER 1&2: Accuton 10” cell aluminum sandwich

CROSSOVER FREQUENCY: 4th order design 2500Hz

CROSSOVER’S ATTENUATION SLOPE:

Woofer: 24dB

Midrange: 24dB

Tweeter: 24dB

CROSSOVER COMPONENTS:

High quality MKP capacitors. Also, high purified OFC, inductors and the metal oxide film resistors with military industrial standard.

CONNECTIVE CABLE: Teflon insulated OCC cable

CONNECTIONS: M-cap Bi-wiring

CABINET MATERIAL: High quality 30mm MDF

FINISH: Natural walnut w/ piano black finish

SPEAKER (HWD): 163cm×35cm×50cm

NET WEIGHT: 93kgs /pc

GROSS WEIGHT: 149kgs /pc

PACKING WOODEN CASE (HWD): 180 x 48 x 76cm
